EGE-4KVM-MV41

4x1 4K HDMI KVM Seamless Switch,QUAD Multiview, PIP,PAP, Mouse Controll

4×1 HDMI 4K KVM Seamless Switch,
QUAD Multivew, PIP, PAP, Mouse Control
HDMI Input, 3840×2160 video resolution

Description

The 4K MultiView KVM Switch is a standalone device which designed to meet the requirement of multi-task. It allows the user to simultaneously monitor up to four HD HDMI multimedia sources on a single HDTV and upscale the resolution up to 4K. Meanwhile, a PC connection is supported, user can also fully access, control and reboot the connected computer through this switch. 4K is a new standard of display which delivering four times the resolution of Full HD. The EGE-4KVM-MV41 series support various input as long as built-in an HDMI connection and upscale the resolution up to 4K. It means the images can be demonstrated sharper and contain more details using the EGE-4KVM-MV41 series.





Spesifications

  • KVM Mouse hopping for MultiView screen
  • Seamless switching between input channels and combined multiple images on single monitor
  • Support HDMI® signals with Deep Color and HDCP 1.4 / 2.2.
  • Support input resolution up to 4K@60Hz, 4:4:4 color sampling
  • Support output resolution up to 4K@60Hz, 4:4:4 color sampling
  • Support upscaling up to 4K@60Hz, 4:4:4 color sampling
  • Support PIP, POP and multi-view layout configurations
  • Support 14 different screen layouts by 6 preset screen layouts and extra 8 customized screen layouts
  • Receive Dolby Digital® 5.1, DTS® 5.1 and uncompressed 7.1 linear PCM audio includes stereo analog
    audio input
    Support stereo audio output
  • Support front panel button, IR remote control, RS232 ,Web UI and keyboard Hot-key.
  • Support firmware upgrade

Box Contents

Diagrams
