4H + 4 CV / 2H HDMI to CAT Audio Matrix 4Play

4×6 HDBase-T Matrix
PoH/ IR/ RS-232
4K@60Hz (YUV 4:4:4)

Categories: , ,
Brand:

Description

This 4×6 HDMI/HDBaseT Matrix supports routing and transmission of video (resolutions up to 4K@60Hz w/ HDMI 2.0 & HDCP 2.2) and audio (multi-channel digital/stereo analog) while providing flexible control via IR, RS-232, Telnet or WebGUI. As many as four HD sources may be routed to any of six destinations via a single Cat.5e/6/7 cable (up to 60m at 1080p or up to 40m at 4K@30Hz). The two HDMI 2.0 outputs support transmission of 6G UltraHD HDMI sources (up to 4K@60Hz, 4:4:4) from any HDMI input or they can mirror any of the HDBaseT outputs for local monitoring. 3D video is also supported when compatible sources and displays are connected. This product supports passing 7.1 channel LPCM digital audio as well as advanced bitstream and HD bitstream audio formats. Additionally, four analog audio outputs are available to provide stereo breakout audio from the associated HDBaseT output (LPCM 2.0 sources only). The Power over HDBaseT (PoH) function can power compatible receivers, providing greater flexibility in your installations. Control is via manual selection buttons, WebGUI, Telnet, RS-232 or IR remote

Spesifications

  • Compatible with HDMI 2.0 , HDCP 1.4 and 2.2
  • Routes 4 HDMI sources to 6 displays using 4 HDBaseT outputs and 2 independent or mirrored HDMI outputs
  • HDBaseT property support: HD video/audio, PoH (Power over HDBaseT), and control (IR/RS-232 passthrough)
  • Supports HDMI output resolutions up to 4K@60Hz (RGB/YUV 4:4:4)
  • Supported HDBaseT resolutions:480i~1080p ,VGA~WUXGA, 4K@24/25/30Hz (RGB, YUV 4:4:4 & YUV 4:2:2) & 4K@60Hz (YUV 4:2:0)
  • Supports automatic 4K@60Hz RGB/YUV 4:4:4 to YUV 4:2:0 transformation for HDBaseT outputs
  • Supports passthrough of all standard digital audio formats: LPCM 2.0/5.1/7.1, Bitstream, and HD Bitstream
  • 4K@30Hz signals can be transmitted up to 35m via Cat.5e/6 and up to 40m via Cat.6a/7
  • Supports Digital to Analog Conversion (DAC)
  • Bi-directional IR and RS-232 support over HDBaseT
  • Enhanced internal and external EDID administration with 4 sets of controllable EDID settings
  • Control via front panel controls, Ethernet (Telnet & WebGUI), RS-232 & IR remote
  • 1U shelf mounted design

Inputs

  • 4x HDMI [4x Uncompressed AV and Data]
  • 1x 3.5mm Stereo Mini-jack [1x Infrared Receiver]
  • 1x 9-pin D-sub [1x RS-232 Data]
  • 1x RJ45 [1x IP Control]
  • 1x USB Type A [1x SERVICE Propriety Data]

Outputs

  • 2x HDMI [2x Uncompressed AV and Data]
  • 4x RJ45 [4x HDMI & Propriety Data]
  • 8x RCA [4x ZONE Stereo (L/R)]
  • 1x 3.5mm Stereo Mini-jack [1x Infrared Emitter]

PSU:

  • 24V/6.25A

Dimensions

  • 482mm [W] x 279mm [D] x 49mm [H]

Net Weight

  • 3642gr

Box Contents

• 1× 4 by 6 HDMI/HDBaseT Matrix

• 1× Remote Control (CR-163)

• 2× IR Extender Cable

• 2× IR Blaster Cable

• 1× 24V/6.25A DC Power Adaptor

• 1× Power Cord

• 1× Rack Ear Set

• 1× Operation Manual

Diagrams
