4K UHD+
4 HDMI Output Module
for EGE-6UHD-16416
This 4-port HDMI Card provides 4 independet high-bandwidth HDMI inputs, paired with IR output on the connected modular matrix. Each HDMI and high-bitrate digital audio. Each of the four analog stereo audio ports can output independently routed audio, or axtract audio from the associated HDMO output (LPCM 2.0 sources only).
• 4 HDMI şnout ports paires with IR output and stereo input ports
• Sİngle-link DVI compatible with the use of an HDMI-DVI adapter
• HDCP 2.2 and HDCP 1.x compliant
• Suppırts up to 4K UHD (18Gbps, 4K@50/60Hz 4:4:4, 8-bit) video
• Supports 10-bit and 12-bit HDR (High Dinamic Range) output
• Supports 12-bit Deep Color up to 1080p-60Hz
• Supports pass-through of audio formats including LPCM 2.0/5.1/7.1,
Bitstream, and HD Bitstream
• Supports stereo audio embedding
• Per-input active signal detection LEDs
• This card’s features are sontrolled by the modular matrix
Inputs
4x HDMI [4x Uncompressed AV and Data]
4x 3.5mm [4x Stereo(L/R)]
Outputs
4x 3.5mm [4x Infrared Emitter]
Dimensions
197mm [W] x 364mm [D] x 29mm [H]
Net Weight
458g
