EGE-CNV-SDIHD

The SDI to HDMI converter allows SD-SDI, HD-SDI and 3G-SDI signals to be shown on HDMI displays while ensuring high bit rates of 2.970 Gbit/s to give you fast signal transmission without any loss. For professionals this means that it is now easier to distribute and extend your 3G SDI signal while giving you the ability to display your work on HDMI displays thanks to the built in HDMI converter.

• Operation at 2.970Gbit/s, 1.485Gbit/s and 270Mbits/s
• Supports SMPTE 425M, SMPTE 424M, SMPTE 292M, SMPTE 259M-C
• Conversion from SMPTE 425M level B to Level A 1080p 50/59.94/60 4:2:2 10-bit
• Connect with other units to extend your signal over long distances

• 3G SDI to HDMI Converter

• 5V DC Power Supply Adaptor

• Operation Manual
