EGE-HDVGA-EX100

• Supports scaling of the HDMI/PC input to a wide range of HDTV and PC output resolutions
• Transmission of uncompressed data over a single 100m/328 ft CAT5e/6/7 cable to a compatible receiver
• Full 5Play™ convergence: Video, Audio, LAN serving, Bi-directional Power over Ethernet (PoE) and Control (IR & RS-232 bypass)
• Supports control of the unit via IR, Remote control, RS-232 and on-panel controls
• Features on-screen display (OSD) selection and display of system settings and information
• Supports bi-directional 24V DC Power over Ethernet (PoE) to or from compatible Receivers over CAT5e/6/7 cable
• Supports Ethernet transmission rates up to 100Mbps to compatible receivers

Inputs

• 1x HDMI [1x Uncompressed AV and Data]
• 1x 15-pin D-sub [1x PC RGBHV]
• 1x 3.5mm Stereo Mini-jack [1x Stereo(L/R)]
• 1x RJ45 [1x LAN Serving]
• 1x 3.5mm Stereo Mini-jack [1x Infrared Receiver]
• 1x 9-pin D-sub [1x RS-232 Data]
• 1x USB Type A [1x SERVICE Propriety Data]

Outputs

• 1x RJ45 [1x HDMI & Propriety Data]
• 1x 3.5mm Stereo Mini-jack [1x Infrared Emitter]

PSU:

• 24V/2.7A

Dimensions

• 145mm [W] x 202mm [D] x 30mm [H]

Net Weight

• 608gr

• HDMI/PC to CAT5e/6/7 with LAN/IR/RS-232/Bidirectional PoE Transmitter

• IR Extender x 1

• IR Blaster x 1 • 24 V/2.7 A DC Power Adaptor

• Power Cable • Remote control with battery(CR-128)

• Operation Manual
