EGE-MFAUD-2CAMP

• Supports digital-to-analog audio conversion (DAC) and analog-to-digital audio conversion (ADC)
• Supports input sampling rates up to 96kHz and output at 48kHz
• Supports 2 passive speaker outputs with 4Ω to 8Ω impedance each
• Speaker output supports 45W/4Ω per channel
• Hi-Efficient 2x45W class D amplification, with efficiency higher than 80%
• Simultaneous sound output on both digital and analog connections
• Supports distances up to 300 meters through industry standard CAT5e/6/7 cables
• Supports control via RS-232, IP (Telnet and WebGUI), IR and on-panel controls
• Sound amplification up to -80dB with volume up moderation at power on

Inputs

• 1x TOSLINK [1x OPTICAL 2 Channel LPCM]
• 1x RCA [1x COAXIAL 2 Channel LPCM]
• 2x RCA [1x Stereo (L/R)]
• 1x 3.5mm Stereo Mini-jack [1x LINE IN Stereo(L/R)]
• 1x 3.5mm Stereo Mini-jack [1x Infrared Receiver]
• 1x 9-pin D-sub [1x RS-232 Data]
• 1x RJ45 [1x IP Control]
• 1x USB Type A [1x SERVICE Propriety Data]
• 1x RJ45 [1x AUDIO-CAT Digital Audio Propriety Data / Propriety Data]

Outputs

• 4x Speaker Binding Posts [1x Speaker Level Stereo Output]

PSU:

• 24V/2.7A

Dimensions

• 215mm [W] x 172mm [D] x 46mm [H]

Net Weight

• 1060g

• 1 x 2-Channel Zone Amplifier

• 1 x Remote Control CR-139

• 1 x 24V/2.7A DC Power Adaptor

• 1 x Power Cable

• 1 x Rack Ears Set

• Operational Manual
