EGE-SCA-HDB-HVGDP

HDMI/DisplayPort/VGA to HDMI Scaler with HDBaseT Output

HDMI/DP/VGA to HDMI/HDBaseT Scaler
Microphone Input
1080p@60Hz

Categories: , ,
Brand:

Description

This HDMI/DP/HDBaseT to HDMI/HDBaseT Scaler supports five inputs including HDMI, VGA, and DisplayPort. Any selected source will be scaled to your preferred resolution for output over HDMI and HDBaseT. HD resolutions up to 1080p@60Hz are supported. This unit also provides audio application flexibility by including multiple unbalanced audio inputs, a 1/4” mic input (with support for optional 48V phantom power) and one line out port. This unit contains an audio DSP engine with auto-mixer and auto-gain functionality, allowing for the mic source to be mixed with the audio from one of the video sources while reducing the background audio in order to enhance the primary audio source. The HDBaseT output provides 24V PoC (Power over Cable) allowing compatible PoC powered HDBaseT Receivers to operate without needing a local power connection. This unit can be easily controlled and configured through the front panel with OSD, IR remote control, RS232, Telnet, or WebGUI. This unit is an ideal solution for presentations in classrooms and conference rooms.

Spesifications

  • Compatible with HDMI, DVI, DisplayPort and HDCP 1.4
  • Video and audio inputs: 2×HDMI, 2×VGA,1×DisplayPort, 3×Unbalanced audio, 1×Mic audio (w/ 48V phantom power option)
  • HDMI and HDBaseT outputs (mirrored)
  • Inputs support HD resolutions up to 1080p@60Hz and PC resolutions from VGA to WUXGA
  • Outputs support resolutions up to 1080p@60Hz
  • Supports pass-through of LPCM 2.0 audio
  • Audio DSP with auto mixer and gain control for mixing audio and reducing background audio
  • HDBaseT feature support: High-Definition video and audio, 24V PoC (Power over Cable) and control (Bi-directional IR & RS-232 pass through)
  • HDBaseT output provides 24V PoC to power to compatible HDBaseT Receivers
  • Supports EDID management
  • Supports IR In and IR Out to receive or transmit IR signals from compatible Receivers with bi-directional IR
  • Remote control provides discrete input source selection
  • Supports control via WebGUI, Telnet, IR remote and RS-232

Inputs

  • 2x HDMI [2x Uncompressed AV and Data]
  • 2x 15-pin D-sub [2x VGA RGBHV]
  • 1x DisplayPort [1x Uncompressed AV]
  • 1x 6.35mm Stereo Jack [1x Microphone]
  • 2x 3.5mm Stereo Mini-jack [2x PC 1 / PC 2 Stereo(L/R)]
  • 1x 3.5mm Stereo Mini-jack [1x LINE-IN Stereo(L/R)]
  • 1x 3.5mm Stereo Mini-jack [1x Infrared Receiver]
  • 1x 9-pin D-sub [1x RS-232 Data]
  • 6x 1-Pin Terminal Block [1x INPUT CONTROL]
  • 1x RJ45 [1x IP Control]
  • 1x USB Type A [1x SERVICE Propriety Data]

Outputs

  • 1x HDMI [1x Uncompressed AV and Data]
  • 1x RJ45 [1x HDMI & Propriety Data]
  • 1x 3.5mm Stereo Mini-jack [1x LINE-OUT Stereo(L/R)]
  • 1x 3.5mm Stereo Mini-jack [1x Infrared Emitter]
  • 1x 3.5mm Stereo Mini-jack [1x RS-232]

PSU:

  • 24V/1.25A

Dimensions

  • 219mm [W] x 165mm [D] x 52mm [H]

Net Weight

  • 1256gr

Box Contents

• 1×HDMI/DP/VGA to HDMI/HDBaseT Scaler

• 1×Remote Control (CR-165)

• 1×IR Blaster Cable

• 1×IR Extender Cable

• 1×15-pin D-sub Male to 3 RCA Cable

• 1×3.5mm to 9-pin D-sub Male Cable

• 1×6-pin Terminal Block

• 1×24V/1.25A Power Adaptor

Diagrams
