EGE-SCA-HDVGCMP-HD

• Supports HDMI, Composite Video, S-Video, PC (VGA) or HD (Component Video) inputs
• Supports HDMI, VGA or Component (with adaptor) outputs
• Supports EDID and HDCP
• Supports analog stereo, optical and coaxial digital inputs and optical digital output, analog stereo output or embedding to HDMI output
• Supports conversion of multiple video formats and audio input to HDMI or PC/HD and analog stereo outputs
• Supports 3D de-interlacing, noise reduction and 3D comb filter
• Supports frame rate conversion
• Control scaler via RS-232, remote and front panel control

Inputs

• 2x HDMI [2x Uncompressed AV and Data]
• 1x 15-pin D-sub [1x PC RGBHV]
• 3x RCA [1x YCbCr Component / YPbPr Component]
• 1x RCA [1x Composite Video]
• 1x S-Video [1x S-video]
• 6x RCA [3x Stereo (L/R)]
• 1x 3.5mm Stereo Mini-jack [1x Stereo(L/R)]
• 1x TOSLINK [1x OPTICAL 2 Channel LPCM]
• 1x 9-pin D-sub [1x RS-232 Data]
• 1x USB Type A [1x SERVICE Propriety Data]

Outputs

• 1x HDMI [1x Uncompressed AV and Data]
• 1x 15-pin D-sub [1x PC/HD RGBHV / YPbPr Component / YCbCr Component]
• 1x 3.5mm Stereo Mini-jack [1x Stereo(L/R)]
• 1x TOSLINK [1x OPTICAL 2 Channel LPCM]

PSU:

• 5V/3A

Dimensions

• 320mm [W] x 182mm [D] x 44mm [H]

Net Weight

• 1600gr

• 1×Multi-Format to HDMI Scaler

• 1×Remote Control (CR-143)

• 1×5V/3A DC Power Adaptor

• 1×15-pin D-sub to 3 RCA Adaptor Cable

• 1×Operation Manual
