EGE-SCA-MI-HDVG

• Supports switching and scaling of multiple A/V inputs to HDMI or VGA outputs
• Supports HDMI output resolutions up to 1080p/WUXGA
• Supports EDID and HDCP
• Supports 3D de-interlace, noise reduction and 3D comb filter
• Supports frame rate conversion
• Control the scaler via RS-232, IP(Telnet/Web GUI) and IR controls
• Supports output timing hot keys switching
• Supports Digital to Analog (DAC) and Analog to Digital (ADC) Audio conversion
• Supports usage without HDCP signal for Apple computers

Inputs

• 3x HDMI [3x Uncompressed AV and Data]
• 3x 15-pin D-sub [3x RGBHV]
• 6x 3.5mm Stereo Mini-jack [6x Stereo(L/R)]
• 3x RCA [1x YPbPr Component]
• 1x RCA [1x Composite Video]
• 4x RCA [2x Stereo (L/R)]
• 1x 9-pin D-sub [1x RS-232 Data]
• 1x 3.5mm Stereo Mini-jack [1x Infrared Receiver]
• 1x RJ45 [1x IP Control]
• 1x USB Type A [1x SERVICE Propriety Data]

Outputs

• 2x HDMI [2x Uncompressed AV and Data]
• 1x 15-pin D-sub [1x RGBHV / YPbPr Component]
• 1x RCA [1x COAX 2 Channel LPCM]
• 1x 3.5mm Stereo Mini-jack [1x Stereo(L/R)]

PSU:

• 5V/3A

Dimensions

• 432mm [W] x 183mm [D] x 47mm [H]

Net Weight

• 2140gr

• 1×Multiple Inputs to HDMI/VGA Scaler

• 1×15-pin D-Sub to 3 RCA Adaptor Cable

• 1×IR Extender Cable

• 1×Remote Control (CR-122)

• 1×5 V/3 A Power Adaptor

• 1×Operation Manual
