EGE-SDI-FO
1500 3G SDI Mini Fiber Optic Extender
3G SDI Fiber Optic Extender
Distance: 10km
1080P@60Hz
Description
- Single mode ST fiber for transmission
- The highest bandwidth: 3Gbps
- The highest resolution: 1080P@60Hz
- The longest transmission distance: 10km
- Support SMPTE 292M(HD SDI) and SMTPE 259M(SD SDI)
- Support SMPTE 424M(3G SDI)
- Distance up to 10km
- Input Impedance 75Ω
- Signal Level: 800mVp p 50mV
- Compliance with RoHS
Spesifications
- Single mode ST fiber for transmission
- The highest bandwidth: 3Gbps
- The highest resolution: 1080P@60Hz
- The longest transmission distance: 10km
- Support SMPTE 292M(HD SDI) and SMTPE 259M(SD SDI)
- Support SMPTE 424M(3G SDI)
- Distance up to 10km
- Input Impedance 75Ω
- Signal Level: 800mVp p 50mV
- Compliance with RoHS
