Description
Video, audio and control transmission over TCP/IP in Unicast (point-to-point) or Multicast (single-to-many) modes Support with 90° increments rotation The analog Line In on the Transmitter sends audio directly to the analog Line Out and is inserted into the HDMI output on connected Receivers
The Mic In on the Receiver sends audio directly to the analog Line Out on the Transmitter Both Tx and Rx may powered directly by PoE when connected to a Gigabit Ethernet switch that provides PoE (802.3af) Supports USB keyboard, mouse and storage extension and IR ,RS-232 bypass Unit can be controlled via WebGUI, Telnet, and front panel controls
Interfaces
Input Port
1 HDMI (Type-A)
1 VGA
1 Unbalanced Stereo (3.5mm)
Output Port
1 VGA
1 Cat.5e/6/7 (RJ45)
1 Unbalanced Stereo (3.5mm)
Control I/O
1 USB Type-B
1 IR Extender [3.5mm]
1 IR Blaster [3.5mm]
1 RS232
Video
HDMI Compliance
HDMI 2.0 (DVI 1.0)
HDCP Compliance
2.2
Input Signal Types
4K@60 8-bit YUV 4:2:0
Output Signal Types
4K@60 8-bit YUV 4:2:0
Resolutions
Maximum Input
HDMI
4096×2160p@60
VGA
1920×1200p@60RB
Maximum Output
VGA
1920×1200p@60RB
Cat.5e/6/7
4096×2160p@60
Audio
Input Signal Types
HDMI, Unbalanced Stereo
Output Signal Types
Unbalanced Stereo
Digital Formats
HDMI 2CH LPCM, 8CH LPCM, Standard Bitstream
