EGE-UHD-HDB-507-TXW/RXW

• HDMI (with 3D format and 4K2K resolution support), HDCP and DVI compliant
• Supports CEC bypass function
• Contemporaneous transmittal of uncompressed video/audio and data over a single CAT5e/6 cable up to 100 m/328 ft
• Supports uncompressed video up to 4K2K resolution (3840×2160@30 Hz or 4096×2160@24 Hz)
• Supports pass-through of high-definition audio formats: LPCM 7.1CH, Dolby TrueHD and DTS-HD Mater Audio
• HDBaseT™ convergence: uncompressed high-definition Video and Audio, LAN serving, Bi-directionlal Power over Cable (PoC) and IR/RS-232 Control pass-through
• Installation friendly

Inputs

• 1x HDMI [1x Uncompressed AV and Data]
• 1x RJ45 [1x LAN Serving]
• 1x 9-pin D-sub [1x RS-232 Data]
• 1x 3.5mm Stereo Mini-jack [1x Infrared Receiver]

Outputs

• 1x RJ45 [1x HDMI & Propriety Data]
• 1x 3.5mm Stereo Mini-jack [1x Infrared Emitter]

PSU:

• 24V/1.25A

Dimensions

• 102mm [W] x 120mm [D] x 25mm [H]

Net Weight

• 252gr

• 1×HDMI over CAT5e/6/7 Transmitter

• 1×HDMI over CAT5e/6/7 Receiver

• 1×IR Blaster (included in Receiver package)

• 1×IR Extender (included in Receiver package)

• 1×24 V/1.25 A DC Power Adaptor (included in Transmitter package)

• 1×Operation Manual
