Description
EGE-VWC2-W-XU is a high-performance video processing server without any operating system. It delivers high quality signal images and real-time video as it adopts large-capacity high-speed FPGA array and processing mechanism of CrossPoint data routing and exchange. Thanks to its hardware-based structure, it features extremely high stability, fast startup speed and supports 365×24 hours of uninterrupted and stable operation. It can be widely used in security monitoring, exhibitions, military command, education and scientific research, government announcements, commercial displays and other industries.
EGE-VWC2-W-2U: 2U(8 in 16 out) Videowall Controller Chassis w/ 2 windows
EGE-VWC2-WO-4U: 4U(16 in 32 out) Videowall Controller Chassis w/ 2 windows
EGE-VWC2-WI-4U: 4U(32 in 16 out) Videowall Controller Chassis w/ 2 windows
EGE-VWC2-W-7U: 7U(72 in 36 out) Videowall Controller Chassis w/ 2 windows
EGE-VWC2-WO-7U: 7U(72 in 72 out) Videowall Controller Chassis w/ 2 windows
Input Board
EGE-VWC2-W-HDMI-I: 4 channels of HDMI Type A (Female), Suppport HDMI1.3 and HDCP，max output resolution 1920*1080@60Hz；Support embedded audio inside HDMI；support OSD on HDMI source，OSD text font type and size , background and foreground color can be adjusted by control software；
EGE-VWC2-W-DVI-I: 4 channels of DVI ，24+5 Pin, DVI-I（Female，Digital Signal Only），Max output resolution 1920*1080@60Hz；
EGE-VWC2-W-IP-I: One port supports to decode 4 channels of 4K or 16 channels of 1080P or 32 channels of 720P or 64 channels of D1 video decoding, supports H.264 and H.265 video compression formats; each IP Plus board supports 4 IP channels, each IP channel supports 1/4/9/16 screen split;
EGE-VWC2-W-4K-I: Support 1 channel of HDMI1.4 input, the maximum support resolution is 3840×2160@30Hz;
EGE-VWC2-W-ROTA-I: HDMI1.3 digital interface, support HDCP, maximum support resolution 1920*1080@60Hz; support 90 degree, 180 degree, 270 degree real-time rotation function;
EGE-VWC2-W-ANDR-I: Android input board for EGE-VWC2-W-XU
EGE-VWC2-W-SDI-I: Support 4-channels of SDI input (BNC female), maximum support resolution 1920*1080@60Hz;
EGE-VWC2-W-CVBS-I: Support PAL/NTSC format, support brightness, contrast, gray scale, saturation adjustment;
Output Board
EGE-VWC2-W-HDMI-O: 4 channels of HDMI Type A (Female), Suppport HDMI1.3 and HDCP，max output resolution 1920*1080@60Hz；supports embedded HDMI audio output when input card supports audio in;
EGE-VWC2-W-DVI-O: 4 channels of DVI ，24+5 Pin, DVI-I(Female，Digital Signal Only)，Max output resolution 1920*1080@60Hz
Other Function
WEB MCU Control Board
Subtitle Board
RPSU(only for 4U/7U)
RPSU(only for 10U/15U)
Windows-based Preview output board
Multiplatform-based Preview output board
Digital Signage Control System
Front panel OSD display and menu buttons
